8.0 Quality assurance requirements
8.1 Acceptance test
9.0 Serviceability
10.0 Philips
Flat panel monitors pixel defect policy
1.0 FOREWORD
This specification describes a 17" SXGA multi-scan color TFT-LCD monitor with max
resolution up to 1280*1024 /76 Hz non-interlaced.
2.0 PRODUCT PROFILE
This display monitor unit is a color display monitor enclosed in PHILIPS global styling
cabinet, which has an integrated tilt and swivel base.
2.1 LCD
2.1.1 Type NR. : LM170E01-A6
Number of Pixels. : 1280 (H) x1024 (V)
Physical Size. : 358.5(w)*296.5(h)*17(d) mm
Pixel Pitch. : 0.264 mm x 0.264 mm
Color pixel arrangement. : RGB vertical stripes
Support Color. : 16.2M colors
Display Mode. : Normally White
Backlight. : CCFL edge light system
Active area. (WXH). : 337.92 x 270.336mm (17" diagonal)
Viewing Angle (CR>=10). : Vertical 140 degree, Horizontal 140 degree (Typ.)
Contrast ratio. : 500:1
White luminance. : 250nits (Typ.)
2.1.2 Type NR. : QD17EL0709
Number of Pixels. : 1280 (H) x1024 (V)
Physical Size. : 358.5(w)*296.5(h)*17.5(d) mm
Pixel Pitch. : 0.264 mm x 0.264 mm
Color pixel arrangement. : RGB vertical stripes
Support Color. : 16.2M colors
Display Mode. : Normally White
Backlight. : CCFL edge light system
Active area. (WXH). : 337.9 x 270.3 mm (17" diagonal)
Viewing Angle (CR>=10). : Vertical 125 degree, Horizontal 140 degree (Typ.)
Contrast ratio. : 500:1
White luminance. : 260nits (Typ.)
2.1.3 Type NR. : CLAA170EA07
Number of Pixels. : 1280 (H) x1024 (V)
Physical Size. : 358.5(w)*296.5(h)*17.5(d) mm
Pixel Pitch. : 0.264 mm x 0.264 mm
Color pixel arrangement. : RGB vertical stripes
Support Color. : 16.2M colors
Display Mode. : Normally White
Backlight. : CCFL edge light system
Active area. (WXH). : 337.92 x 270.336 mm (17" diagonal)
Viewing Angle (CR>=10). : Vertical 130 degree, Horizontal 140 degree (Typ.)
Contrast ratio. : 500:1
White luminance. : 300nits (Typ.)
GENERAL PRODUCT SPECIFICATION(Continued)
BRAND : PHILIPS
17 inch LCD Monitor
TYPE :170B6CG/00
8639 000 16159
2004-12-24
2004-12-24
590
Peter V.
