GENERAL PRODUCT SPECIFICATION(Continued)
3). Audio
Inputsignal: 500mVrms
Loudspeaker (Impedance: 16 Ohm +/-15%): 2W+2W stereo for RMSPower
Frequency range: 320Hz - 13KHz
Headphoneconnection will mute speakers
4). USB Adaptor
Inputsignal: Upstream input (V
BUS
, D+, D-, GND) via USB-B receptacle.
Outputsignal: Downstream output (V
BUS
, D+, D-, GND) through USB-A receptacle
3.2 Interface
3.2.1 D-Sub Cable
Length. : 1.5 M +/- 50 mm
Connector type. : D-Submalewith DDC-2B pin assignments.
Blueconnector thumb-operated jackscrews
Pin Assignment:
3.2.2 DVI Cable
The inputsignals are applied to the display through DVI-D cable.
Length. : 1.8 M +/- 50 mm
Connector type. : DVI-D male with DDC-2B pin assignments
White connector thumb-operated
jackscrews
Pin Assignment:
PIN No. SIGNAL
1 Red video input
2Green video input/syncon green
3Bluevideo input
4GND
5GND- Cable detect
6 Red video GND
7Green video GND
8Bluevideo GND
9 DDC +3.3V or +5V
10 LogicGND
11 GND
12 Serial data line (SDA)
13 H-sync/H+V
14 V-sync
15 Data clock line (SCL)
