GENERAL PRODUCT SPECIFICATION(Continued)
MODENO.33 34
RESOLUTION 960X720 960X720
Dot clock(MHz) 57.58 72.42
F h 44.76kHz 56.4kHz
A(us ) 22.34(1286 dots) 17.73(1284 dots)
B (us ) 1.72(99 dots) 1.44(104 dots)
C (us ) 2.58(148 dots) 2.21(160 dots)
D (us ) 16.67(960 dots) 13.256(960 dots)
E(us ) 0.856(49 dots) 0.780(56 dots)
F v 60Hz 75Hz
O(ms ) 16.667(746 lines) 13.333(752 lines)
P(ms ) 0.067(2.9 lines) 0.053(3lines)
Q (ms ) 0.495(22 lines) 0.5(28 lines)
R(ms ) 16.081(720 lines) 12.766(720 lines)
S(ms ) 0.0228(1lines) 0.0184(1lines)
SYNC. H/V -/ + -/ +
POLARITY
SEP . SYNCY Y
A :H-Total O :V-Total
B:H-Syncwidth P :V-Syncwidth
C : H- Back porch Q : V- Back porch
D:H-Video width R :V-Video width
E :H-Front porch S :V-Front porch
3.3.3 Horizontal scanning
Sync polarity. : Positive or Negative
Scanningfrequency. : 30 - 83 KHz
3.3.4 Vertical scanning
Sync polarity. : Positive or Negative
Scanningfrequency. : 56 - 76 Hz
3.4 Power inputconnection
Power-cord length. : 1.5 M
Power-cord type. : 3 leads power cord with protective earth plug.
3.5 Power management
The power co
nsumption and the status indicati on of the set with power managementfunction are as below:
1) DPMS for Analog signal.
AccordingtoVESA power savingsignal. TCO’03 power savingrequirement, EPA energy star requirement.
Status H-syncV-syncVideo Power LED
On On On Active <45W Green /With Audio
On On On Active <35W
Green /Without
Audio
Stand-by Off On Blanked <1W
Amber
Suspend On Off Blanked <1W
Amber
Off Off Off Blanked <1W Amber
DC Power off N/A <1W Off
