GENERAL PRODUCT SPECIFICATION(Continued)
MODENO. 9 10 11 12
RESOLUTION 800 x 600 800 x 600 800 x 600 800 x 600
Dot clock(MHz) 40 50 49.498 56.251
f h 37.9kHz 48.077kHz 46.9kHz 53.7kHz
A(us ) 26.4 (1056 dots) 20.80 (1040dots) 21.333 (1056 dots) 18.631 (1048 dots)
B (us ) 3.2 ( 128 dots) 2.400 ( 120 dots) 1.616 ( 80 dots) 1.138 ( 64 dots)
C (us ) 2.2 ( 88 dots) 1.280 ( 64 dots) 3.232 ( 160 dots) 2.702 ( 152 dots)
D (us ) 20 ( 800 dots) 16.00 ( 800 dots) 16.162 ( 800 dots) 14.222 ( 800 dots)
E(us ) 1 ( 40 dots) 1.120 ( 56 dots) 0.323 ( 16 dots) 0.569 ( 32 dots)
f v 60Hz 72Hz ( 72.188) 75Hz 85Hz
O(ms ) 16.579 (628 lines) 13.85 (666 lines) 13.333 (625 lines) 11.756(631 lines)
P(ms ) 0.106 ( 4lines) 0.125 ( 6lines) 0.064 ( 3lines) 0.056 ( 3lines)
Q (ms ) 0.607 ( 23 lines) 0.478 ( 23 lines) 0.448 ( 21 lines) 0.503 ( 27 lines)
R(ms ) 15.84 (600lines) 12.48 (600 lines) 12.8 (600 lines) 11.179 (600 lines)
S(ms ) 0.026 ( 1line ) 0.770 ( 37 line ) 0.021 ( 1line ) 0.018 ( 1lines)
SYNC. H/V + / + + / + + / + + / +
POLARITY
SEP . SYNCY Y Y Y
MODENO.13 14 15 16
RESOLUTION 832 x 624 1024 x 768 1024 x 768 1024 x 768
Dot clock(MHz) 57.28 65 75 78.75
f h 49.7kHz 48.363kHz 56.5kHz 60kHz
A(us ) 20.11(1152 dots) 20.677(1344 dots) 17.707(1328 dots) 16.66 (1312dots)
B (us ) 1.117(64 dots) 2.092(136 dots) 1.813(136 dots) 1.219 ( 96 dots)
C (us ) 3.91(224 dots) 2.462(160 dots) 1.920(144 dots) 2.235 ( 176 dots)
D (us ) 14.52(832 dots) 15.754(1024 dots) 13.653(1024 dots) 13.003 ( 1024 dots)
E(us ) 0.563(32 dots) 0.369(24 dots) 0.321 (24 dots) 0.203 ( 16 dots)
f v 75Hz 60.004Hz 70.004Hz 75Hz ( 75.000)
O(ms ) 13.41(667 lines) 16.666(806 lines) 14.272(806 lines) 13.328 (800 lines)
P(ms ) 0.06(3lines) 0.124(6lines) 0.106(6lines) 0.05( 3lines)
Q (ms ) 0.784(39 lines) 0.600(29 lines) 0.514(29 lines) 0.446 ( 28 lines)
R(ms ) 12.55(624 lines) 15.880(768 lines) 13.599(768 lines) 12.80 (768 lines)
S(ms ) 0.016(1lines) 0.062(3lines) 0.053(3lines) 0.017 ( 1line )
SYNC. H/V +/+ - / - -/- + / +
POLARITY
SEP . SYNCY Y Y Y
MODENO.17 18 19 20
RESOLUTION 1024 x 768 1024 x 768 1152 x 864 1152 x 864
Dot clock(MHz) 83.096 94.5 79.9 94.5
f h 61.1kHz 68.7kHz 54.0kHz 63.9kHz
A(us ) 16.367 (1360dots) 14.561 (1376 dots) 18.523(1480 dots) 15.661(1480 dots)
B (us ) 1.348 ( 112 dots) 1.016 ( 96 dots) 1.952(156 dots) 1.016(96 dots)
C (us ) 2.022 ( 168 dots) 2.201 ( 208 dots) 1.352(108 dots) 1.116(105 dots)
D (us ) 12.323 ( 1024 dots) 10.836 ( 1024 dots) 14.418(1152 dots) 12.19(1152 dots)
E(us ) 0.674 ( 56 dots) 0.508 ( 48 dots) 0.801(64 dots) 1.339(127 dots)
f v 76Hz 85Hz 60Hz 70Hz
O(ms ) 13.142 (803 lines) 11.765 (808 lines) 16.671(900lines) 14.283(912lines)
P(ms ) 0.049 ( 3lines) 0.044 ( 3lines) 0.148(8lines) 0.047(3lines)
Q (ms ) 0.507 ( 31 lines) 0.524 ( 36 lines) 0.445(24 lines) 0.689(44 lines)
R(ms ) 12.57 (768 lines) 11.183 (768lines) 16.004(864 lines) 13.531(864 lines)
S(ms ) 0.016 ( 1line ) 0.014 ( 1line ) 0.074(4lines) 0.016(1lines)
SYNC. H/V + / + + / + +/+ +/+
POLARITY
SEP . SYNCY Y Y Y
