PHILIPS 3000 V2 04 SERVICE MODE
6/9
PresstheEspressobuttontoopentheEV
Action by user LED INDICATION
Led
NoBeans
Led
NoWater
Led
GenAlarm
Led Dreg
drawer full
It is possible to hear the “click” from ElectroValve. The Led
NoBeans is switched on
ON NA NA NA
PressandreleasetheCoeebuttontoswitchonthePump(100impulses)
Action by user LED INDICATION
Led
NoBeans
Led
NoWater
Led
GenAlarm
Led Dreg
drawer full
The water goes out from the dispensing spout,the NoWa-
ter LED blink every Flowmeter pulse.
NA BLINK NA NA
ERROR: the NoWater LED does’t ashing
and after 5sec this LED Switch ON; check:
1) The EV (open?)
2) Pump (is ON?),
3) The owmeter (works rightly?)
4) the wiring from the owmeter to the
CPU/POWER board (JP5)
5) the wiring from the pump to the
CPU/POWER board (JP24)
NA ON NA NA
PresstheCoeebuttontomoveBUtohome
Action by user LED INDICATION
Led
NoBeans
Led
NoWater
Led
GenAlarm
Led Dreg
drawer full
When the BU reaches the home position the Led NoBeans
is switched on
ON NA NA NA
ERROR: Led NoBeans remains o, Check the work mi-
croswitch (broken?), the BU motor (blocked?) and the wi-
ring (JP16).
NA NA NA NA
ERROR: led GenAlarm Switch ON; the absorbed current
is much more 300mA (with BU) or 200mA (without BU)
check the BU and the motor
NA NA ON NA
Finishcondition: With BU, Drag Drawer, door closed LED INDICATION
Led
NoBeans
Led
NoWater
Led
GenAlarm
Led Dreg
drawer full
OFF OFF OFF OFF
Level 4 (Pump)
Start condition: BU not inserted, Drag drawer and
service door closed, no water sensor
LED INDICATION
Led
NoBeans
Led
NoWater
Led
GenAlarm
Led Dreg
drawer full
OFF OFF OFF OFF
If the Dreg drawer is not inserted or the Service door is
not closed the EV cannot be opened and test cannot be
performed. If these 2 inputs are not in the right position,
Led Dreg drawer full will be RED
NA NA NA ON
