Philips DPM8000 - 1 Hardware Specification; Connectivity; Built-In Microphone; Microphone Sensitivities

Page 6 DPM 8000 series - Technical Specification and Advanced Device Configuration
1. Hardware Specification
1.1. Connectivity
Headphone: 3,5mm Jack
Microphone: 3,5mm Jack
USB: USB2.0 High-Speed.
Micro-USB Connector
1.2. Built-In Microphone
1.3. Microphone sensitivities
External Microphone Input
Full Scale Input Voltage (mVrms)
Ext. Microphone low
11,52mV
Ext. Microphone mid
8,15mV
Ext. Microphone high
2,43mV
Line-In Input
Full Scale Input Voltage (mVrms)
Line-In low
229,75mV
Line-In mid
162,65mV
Line-In high
48,56mV
Omnidirectional Microphone - Meeting
