Page 8 DPM 8000 series - Technical Specification and Advanced Device Configuration
1.7. Sound
Built-In round dynamic speaker with 28mm diameter, 200mW output power.
1.8. Headphone Output
RL (Ohm) Pout max (mW)
32 6,4 mW
16 8,35 mW
1.9. Power
Philips Li-Ion rechargeable battery type ACC8100. 3,7V 1000mAh 3,7Wh
1.10. Security
Real time AES 256bits File encryptions.
Device security with PIN and PUK Code
1.11. DPM8500 Barcode scanner
Scan Engine: CCD-based single line.
Barcode type
UPC-A
UPC-E
EAN-8
EAN-13
