02.9687.0001 C 31 October 2013 93
NOTE: Philips Vari-Lite reserves the right to change details of design, materials and finishes. Specifications are
subject to change without notice. Philips VARI
❋LITE automated lighting equipment is made in the U.S.A.
APPENDIX B.
Technical Specifications
Mechanical
Color Mixing System
All models feature a three filter CYM cross-fading mechanism
plus a fixed color wheel with 8 interchangeable color filters
and 1 open space. Fixed wheel is capable of continuous
rotation for additional effects.
Gobo Wheels
• All models feature one rotating gobo wheel with seven rotatable,
indexable gobo positions and one open position. One fixed
gobo wheel with 10 easily loaded patterns and one open position capable of continuous
rotation for additional effects. 17 total gobos positions.
Note: VL440 / VL770 / VL880 Luminaires accept glass gobos only. Use of metal gobos in these
luminaires may damage gobo assembly and will void the luminaire warranty.
Frost and Prism Capability
Independent, drop-in armature with frost glass. Second, independent, drop-in armature
with rotating and indexable four facet prism. Both the frost and prism pieces are
interchangeable.
Pan/Tilt
Smooth, time-controlled continuous motion by way of a high-power, three-phase stepper
motor system.
• Range: Pan - 540° , Tilt - 260°.
• Pan/Tilt Accuracy: 0.3° resolution.
Weights:
• VL440 Spot: 56 lbs. (25.5 kg)
• VL770 Spot: 56 lbs. (25.5 kg)
• VL880 Spot: 56 lbs. (25.5 kg)
Spacing:
All models hang on 23 inch (58.5 cm) centers. Refer to illustration on page 21.
