Philips VL440 - VL880 Spot Control Channel Functions

OPERATION : LUMINAIRE TIMING
3
02.9687.0001 C 31 October 2013 57
VL880 Spot Control Channel Functions
Notes:
• When resetting fixtures to Defaults, settings in Bold will be activated.
• DMX values not shown are for future use.
•
† Full Luminaire ReBoot will douse lamp and restart the Main Control Board (MCB).
• * Note that these functions do not require the 3 second rule to execute. All other values do require
3 second rule.
Table 12: VL880 Spot Control Channel Functions
Control Channel Function
Control Channel Value (VL880 Spot Only)
DMX Value After 3 Secs
Default Console Value (Idle) 0 0
Display - Menu Settings / Off 3 - 4 0
Reset Fixture to Defaults 5 - 7 0
Edge Track ON 11 - 13 N/A*
Edge Track OFF (Norm) 14 - 16 N/A*
Color Snap ON 20 - 25 N/A*
Color Snap OFF (Norm) 30 - 35 N/A*
Dimmer Snap ON 40 - 45 N/A*
Dimmer Snap OFF (Norm) 50 - 55 N/A*
Motor Mini-Stepping ON / OFF 60 - 65 0
Iris 1 Installed 70 - 72 0
Iris 2 Installed 73 - 75 0
Full Luminaire Recal 81 - 87 0
Full Luminaire Reboot
† 91 - 97 0
Recal Color 100 - 104 0
Recal Gobo 112 - 116 0
Recal Beam 126 - 130 0
Recal Dim / Strobe 138 - 142 0
Lamp OFF 165 - 171 0
Lamp Strike 249 - 255 0
