Philips VL440 - Diagnostic Tests; Test Descriptions

MENU SYSTEM : SELF TESTS
4
02.9687.0001 C 31 October 2013 75
Diagnostic Tests
The following diagnostic tests are available in the test menu.
Test Descriptions
All Seq...............Tests all functions in sequential order.
Pan/Tilt..............Tests different pan and tilt movements.
Pan....................Tests different pan movements.
Tilt .....................Tests different tilt movements.
Strobe................Tests strobe operation.
Dimmer..............Tests different dimmer operation.
Cyan..................Tests Cyan color wheel movements.
Yellow................Tests Yellow color wheel movements.
Magenta............Tests Magenta color wheel movements.
Color Mix...........Tests operation of the color mixing system.
Color Wheel ......Tests fixed color wheel operation.
FixGobo.............Tests fixed gobo wheel movement.
Rotating Gobo...Tests rotating gobo wheel operation.
Gobo Index........Tests rotating gobos movement.
Edge..................Tests edge movement.
Zoom.................Tests zoom movements.
Iris .....................Tests iris movement.
Frost .................Tests frost operation / movement.
Prism.................Tests prism operation / movement.
Lamp.................Allows user to manually put luminaire in position to align lamp.
Encoder.............Disables pan and tilt and displays encoder value.
Temperature......Displays LVS or MCB temperatures (in
o
C).
Fan Speeds.......Displays various fans’ speed.
