Philips VL440 - Troubleshooting Guide

TROUBLESHOOTING AND MAINTENANCE
A
02.9687.0001 C 31 October 2013 81
Troubleshooting Guide
If a problem is suspected, first try recalibrating the luminaire to prompt an error message. The chart
below provides possible causes and remedies for various error messages and/or symptoms.
CAUTION: Some troubleshooting is included for reference only. Performing remedies may void
product warranty. Refer to the Vari-Lite Limited Warranty card included with the product.
Table A-2: Troubleshooting Guide
Message Symptom Description Possible Cause/Remedy
Lamp
Power
Douse
Lamp does not strike
upon start-up
Lamp Off option is config-
ured
- Reconfigure lamp startup option in Lamp config
menu.
n/a Lamp douses frequently Lamp Douse Fan failure...
- check head and enclosure fans for proper
operation.
Ballast overheating...
- operating within the specified ambient
temperature?
- check enclosure vents for debris / dirt.
- check fan settings in menu.
- check enclosure fans for proper operation.
NOTE: Upon initial power up, ballast fans will run for
a few seconds and then operate as needed.
Enclosure vents must be clear of debris and dirt to
allow proper airflow.
n/a Lamp will not strike Lamp Strike Failure Lamp cutout switch disengaged...
- check lamp cutout switches at lamp box and fan
ducts.
Bad lamp...
- replace lamp.
Low input voltage...
- check input power (must be 100 to 240 VAC).
n/a Luminaire behaves
oddly
Profile Not Matched Profile not set correctly...
- check Setup menu for correct type (console patch
/ profile).
n/a Luminaire does not
power up
No power Circuit not energized...
- verify circuit breaker (at source) is turned on.
Not plugged in...
- ensure A/C cable is connected to power source.
n/a Self tests will not run or
software download does
not work from luminaire.
DMX Data Input Detecting DMX data...
- disconnect DMX input cable.
n/a No response to DMX
data
DMX Failure DMX connector disconnected...
- check DMX DATA IN connection.
n/a Erratic control of
luminaire
DMX Termination No DMX termination or termination not correct...
- check for DMX terminator.
n/a Iris operation is not cor-
rect
Iris setting not correct
Refer to “Iris Operation” on page 35.
