VL440 Spot Channel Mapping
These tables assume a DMX start address of 1. When a different starting address is used, this address
becomes channel 1 function and other functions follow in sequence.
Table 5: VL440 Spot Channel Mapping
DMX Channel Parameters Range (DMX) Range (%) Default Value* Description
1 Intensity
0 (closed) - 255
(open)
0 - 100% 0
Linear Intensity control from 0 (closed) to 255
(open).
2 Pan Hi Byte
0 - 65535 0 - 100% 32768 16 bit control of Pan 540°of movement.
3 Pan Lo Byte
4 Tilt Hi Byte
0 - 65535 0 - 100% 32768 16 bit control of Tilt 260° of movement.
5 Tilt Lo Byte
6 Edge 0 - 255 0 - 100% 0 Controls Edge lens from 0 to 255.
7 Zoom 0 - 255 0 - 100% 0 Controls zoom assy. 0 (narrow) to 255 (wide).
8 Cyan 0 - 255 0 - 100% 0
Controls Cyan color wheel as follows:
Open to Full Saturation = DMX 0 - 216
9 Yellow 0 - 255 0 - 100% 0
Controls Yellow color wheel as follows:
Open to Full Saturation = DMX 0 - 216
10 Magenta 0 - 255 0 - 100% 0
Controls Magenta color wheel as follows:
Open to Full Saturation = DMX 0 - 216
11 Color Wheel 0 - 255 0 - 100% 0
Controls Static Color Wheel. Linear control from 0
to 216. From 217 - 255 will spin the color wheel in
either direction. Bold number indicates center
values for each color.
Open (No Color) = DMX 0 (0 - 14)
Red = DMX 24 (15 - 34)
Blue = DMX 47 (35 - 58)
Kelly Green = DMX 72 59 - 82
Magenta = DMX 95 (83 - 106)
CTO = DMX 119 (107 - 130)
Flesh Pink = DMX 143 (131 - 156)
Dark Orange = DMX 168 (157 - 179)
Congo Blue = DMX 191 (180 - 201)
Open (No Color) = DMX 202 - 216
Spin Fast to Slow = DMX 217 - 234
Stop = DMX 235 - 237
Spin Slow to Fast = DMX 238 - 255
12
Fixed Gobo
Wheel
0 - 255 0 - 100% 0
Controls Fixed Gobo Wheel. Linear control from
Wheel 0 to 216. From 217 to 255 will give differ-
ent speeds of wheel spin. Bold type below
denotes center values.(note, half gobo positioning
is not possible)
Open (No Gobo) = DMX 0 (0 - 9)
Gobo 1 = DMX 18 (10 - 27)
Gobo 2 = DMX 36 (28 - 45)
Gobo 3 = DMX 54 (46 - 63)
Gobo 4 = DMX 72 (64 - 81)
Gobo 5 = DMX 90 (82 - 99)
Gobo 6 = DMX 108 (100 - 117)
Gobo 7 = DMX 126 (118 - 135)
Gobo 8 = DMX 144 (136 - 153)
Gobo 9 = DMX 162 (154 - 171)
Gobo 10 = DMX 180 (172 - 189)
Open (No Gobo) = DMX 198 (190 - 216)
Spin Fast to Slow = DMX 217 - 234
Stop = DMX 235 - 237
Spin Slow to Fast = DMX 238 - 255
