OPERATION : DMX OPERATION
3
02.9687.0001 C 31 October 2013 39
13
Rotating Gobo
Wheel
0 - 255 0 - 100% 0
Controls Rotating Gobo Wheel using the following
(note, half gobo positioning is not possible):
Open Index (No Gobo) DMX = 0
Gobo 1 (Index) DMX = 14
Gobo 2 (Index) DMX = 28
Gobo 3 (Index) DMX = 42
Gobo 4 (Index) DMX = 56
Gobo 5 (Index) DMX = 70
Gobo 6 (Index) DMX = 84
Gobo 7 (Index) DMX = 98
Open Rotation (No Gobo) DMX = 112
Gobo 1 (Rotate) DMX = 126
Gobo 2 (Rotate) DMX = 140
Gobo 3 (Rotate) DMX = 154
Gobo 4 (Rotate) DMX = 168
Gobo 5 (Rotate) DMX = 182
Gobo 6 (Rotate) DMX = 196
Gobo 7 (Rotate) DMX = 210
Open DMX = 214
Spin Fast to Slow DMX = 217 - 234
Stop DMX = 235 - 237
Spin Slow to Fast DMX = 238 - 255
14
Rotating Gobo
Index / Rotate
0 - 65535 0 - 100% 32768
16 bit control of the Rotating Gobo Wheel's index
and rotation in either direction.
Rotate Fast to Slow << = DMX 0 - 32755
Rotate STOP = DMX 32756 - 32780
Rotate Slow to Fast >> = DMX 32781 - 65535
15
16 Beam Iris 0 - 255 0 - 100% 0
Controls beam size iris from 0 (open) to 255
(small).
17 Strobe 0 - 255 0 - 100% 0
Controls strobe operations as follows:
Open = DMX 0 - 2
Closed = DMX 3 - 5
Slow Rand = DMX 6 - 7
Med Rand = DMX 8 - 10
Fast Rand = DMX 11 - 12
Strobe Range = DMX 13 - 127 (fastest)
18 Frost 0 - 255 0 - 100% 0
Controls frost mechanism. Linear control from No
Frost (0) to Full Frost (255).
19 Prism 0 - 255 0 - 100% 0
Controls prism mechanism.
Prism Out = DMX 0 - 2
Prism In (Index) = DMX 3 - 127
Prism In (Rotate) = DMX 128 - 255
20
Prism Rotate -
High
0 - 65535 0 - 100% 32768
16 bit control of prism index or rotation.
Rotate Fast to Slow << = DMX 0 - 32755
Rotate STOP = DMX 32756 - 32780
Rotate Slow to Fast >> = DMX 32781 - 65535
21
Prism Rotate -
Low
22 Not Used - - - For Future Use
23 Not Used - - - For Future Use
24 Not Used - - - For Future Use
25 Not Used - - - For Future Use
26 Focus Time 0 - 255 0 - 100% 255
Allows for luminaire timing of pan and tilt. Profile
should default to DMX 255 for smoothest console
timing.
27 Color Time 0 - 255 0 - 100% 255
Allows for luminaire timing of color wheel func-
tions. Profile should default to DMX 255 for
smoothest console timing.
28 Beam Time 0 - 255 0 - 100% 255
Allows for luminaire timing of beam functions.
Profile should default to DMX 255 for smoothest
console timing.
Table 5: VL440 Spot Channel Mapping
DMX Channel Parameters Range (DMX) Range (%) Default Value* Description
