Luminaire Components
Below is a brief description of the major assemblies of the VL440 / VL770 / VL880 Luminaires.
Luminaire Head Assembly - Houses color
system, gobos, lenses, filters, reflector, and lamp.
Enclosure Assembly -
Houses ballast, menu system,
pan motor, and AC input
connection, and DMX512
connections.
Yoke Assembly -
Houses tilt motor and
routes cables to / from
head and enclosure
assemblies.
