Fixed Gobo Wheel
• Figure 3-3 on page 34 shows the standard gobo load for the fixed gobo wheel.
• When ordering a custom fixed gobo, use the following order guidelines:
Note: "XXXX" represents gobo or gag pattern number. For all available patterns and their associated
numbers, refer to VARI❋IMAGE System page on the Philips Vari-Lite web site or contact your local
regional sales manager or Authorized VARI❋LITE Dealer.
• Standard load fixed gobos are outlined in Table 2, “Rotating Gobo Wheel - Standard Effects and
Positions”.
- Continued next page -
Order Number Description
41.6004.XXXX Fixed Gobo, VL440/770/880
Table 3: VL880 Spot Fixed Gobo Wheel - Effects and Positions
Position Gobo Gobo Part Number
0 (Open) None None
1 Pebbles 41.6004.7002
2 Dust Breakup 41.6004.7025
3 Medium Circle 41.6004.6001
4 Night Sky 41.6004.5011
5 Leaves 41.6004.5501
6 Horizontal Bars 41.6004.4201
7 Block Breakup 41.6004.7015
8 Tribal Breakup 41.6004.5523
9 Wave 41.6004.7008
10 Bathtub Drain 41.6004.4001
To Next Page
