VARI❋LITE - VL440 / VL770 / VL880 LUMINAIRE USER’S MANUAL
24 31 October 2013 02.9687.0001 C
Figure 2-10: Hanging Dimensions and Clearances
Floor Mounting the Luminaire
All luminaires included in this manual are designed to sit directly on its base in a floor installation
application. When used in this type of application, be sure to leave enough space around the luminaire
to allow proper, uninterrupted airflow for cooling and movement.
24.26 in
616.2 mm
18.88 in
479.5 mm
23.00 in
584.2 mm
22.25 in
565.2 mm
Safety Cable:
Recommended for hanging installations.
May be required by local codes. Safety
cable is sold separately.
