VARI❋LITE - VL440 / VL770 / VL880 LUMINAIRE USER’S MANUAL
40 31 October 2013 02.9687.0001 C
Notes:
Default Values: *Denotes recommended console default settings.
Use of Timing Channels: The default value setting in the profile should be 255 (proportional control) to allow smooth movement when using console timing. The
Timing channel data should change as a snap. A zero value will give the fastest move but without any smoothing, this can look steppy in console-timed moves.
**Requires 3 second rule. Set value for 3 seconds and then give a discrete "0". Once executed, the dimmer shall close, iris shall set to selection, and dimmer shall
reopen.
To use a timing channel instead of console timing it is necessary to set the timing channel to the desired value and set cue and/or parameter time to zero. A
combination of time controls can produce unexpected results. Refer to “Luminaire Timing” on page 47 for more information.
Timing Channel Control: The luminaire uses the timing channel value to calculate a smooth continuous movement for a given time and transition.
29 Gobo Time 0 - 255 0 - 100% 255
Allows for luminaire timing of gobo wheel func-
tions. Profile should default to DMX 255 for
smoothest console timing.
30 Control 0 - 255 0 - 100% 0
Used to strike/douse the lamp, set lamp levels,
and other various functions, as well as resetting
the luminaire via the console. DMX values are:
Default Console Value (Idle) = DMX 0
Display-Menu ON/OFF = DMX 3 - 4
Reset Fixture to Defaults = DMX 5 - 7
*Edge Track ON = DMX 11 - 13
*Edge Track OFF (Norm) = DMX 14 - 16
*Color Snap ON = DMX 20 - 25
*Color Snap OFF (Norm) = DMX 30 - 35
*Dimmer Snap ON = DMX 40 - 45
*Dimmer Snap OFF (Norm) = DMX 50 - 55
Motor Mini-Stepping ON/OFF = DMX 60 - 65
Iris 1 Installed = DMX 70 - 72 **
Iris 2 Installed = DMX 73 - 75 **
Full Luminaire ReCal = DMX 81 - 87
Full Luminaire ReBoot† = DMX 91 - 97
ReCal Color = DMX 100 - 104
ReCal Gobo = DMX 112 - 116
ReCal Beam = DMX 126 - 130
ReCal Dim/Strobe = DMX 138 - 142
Lamp OFF = DMX 165 - 171
Lamp Strike = DMX 249 - 255
When resetting fixtures to Defaults, settings in
Bold will be activated.
† Full Luminaire ReBoot will douse lamp and
restart the Main Control Board (MCB).
* Note that these functions do not require the 3
second rule to execute. All other values do
require 3 second rule.
**Requires 3 second rule. Set value for 3 seconds
and then give a discrete "0". Once executed, the
dimmer shall close, iris shall set to selection, and
dimmer shall reopen.
Table 5: VL440 Spot Channel Mapping
DMX Channel Parameters Range (DMX) Range (%) Default Value* Description
