INSTALLATION : POWER AND DATA CABLING REQUIREMENTS
2
02.9687.0001 C 31 October 2013 15
.
WARNING: It is not recommended to power any VARI❋LITE luminaire from a dimmer - even in
'NONDIM' mode. Dimmer and non-dim modules are not suitable sources of power because their
output modifies the AC wave form. This may work for a short time, but will eventually result in power
problems, luminaire mis-operation and/or failure and may void the luminaire’s warranty.
Table 2-3: VL880 Spot Luminaire - Current vs. Voltage (800W Lamp)
AC Voltage @
60Hz
Total Luminaire
Current (Motor +
Lamp Current)
100V 12.0A
110V 10.9A
120V 10.0A
130V 9.2A
140V 8.6A
160V 7.5A
180V 6.7A
200V 6.0A
220V 5.5A
240V 5.0A
