VARI❋LITE - VL440 / VL770 / VL880 LUMINAIRE USER’S MANUAL
72 31 October 2013 02.9687.0001 C
Strobe Strobe Specifies strobe function for manual control (Manual) or for testing (Test).
Swap Swap Swaps pan and tilt functions for special focus requirements such as moving mirror
mechanisms.
Test System Tests Accesses diagnostic tests for luminaire’s mechanisms.
Tilt Tilt Specifies tilt function for manual control (Manual) or tilt encoder for testing (Test).
VL440 VL440 Spot Sets the unit as a VL440 Spot Luminaire (IMPORTANT! you must set this setting to
the proper parameter or damage to the fixture shall occur and the warranty will be
void).
VL770
VL770 Spot Sets the unit as a VL770 Spot Luminaire (IMPORTANT! you must set this setting to
the proper parameter or damage to the fixture shall occur and the warranty will be
void).
VL880
VL880 Spot Sets the unit as a VL880 Spot Luminaire (IMPORTANT! you must set this setting to
the proper parameter or damage to the fixture shall occur and the warranty will be
void).
Version
Software Version Displays current software version by date (XX/XX/XX).
Yellow Yellow Color Wheel Specifies Yellow color wheel for manual control (Manual) or for testing (Test).
Zoom Zoom Specifies zoom function for manual control (Manual) or for testing (Test).
Table 4-2: Menu Function Definitions (Continued)
Display Definition Purpose
