EV Charge Control Basic
58 / 68
PHOENIX CONTACT 106377_en_04
Hold-
ing
4014 16 bits Read/write Retentive Threshold value for maximum
charging current (S1/DIP
switches 5 + 6), with analog
evaluation of input CCR
Integer in mV
Default = 10,000 mV
4015 16 bits Read/write Retentive Update time for adapting the
charging current, with analog
evaluation of input CCR
Integer in s
Default = 10 s
5004 16 bits Read/write Retentive Configuring input IN Integer
0: Without internal pull-up resis-
tor
1: Internal pull-up resistor con-
nected
5500 16 bits Read/write Retentive Function assignment for digi-
tal output OUT
Integer, according to Table 9-3
Default = mapping to register
23003
5501 16 bits Read/write Retentive Function assignment for digi-
tal output ERR
Integer, according to Table 9-3
Default = status E or F
5502 16 bits Read/write Retentive Function assignment for digi-
tal output CHG
Integer, according to Table 9-3
Default = vehicle is loading,
charging contactor is closed
5503 16 bits Read/write Retentive Function assignment for digi-
tal output CON
Integer, according to Table 9-3
Default = vehicle connected in
status B, C, or D
5600 16 bits Read/write Retentive Behavior of digital output OUT
in status ON
Only takes effect if register
5500 ≠ 0
Integer
1: On
2: Flashing (1 Hz)
5601 16 bits Read/write Retentive Behavior of digital output ERR
in status ON
Only takes effect if register
5501 ≠ 0
Integer
1: On
2: Flashing (1 Hz)
5602 16 bits Read/write Retentive Behavior of digital output CHG
in status ON
Only takes effect if register
5502 ≠ 0
Integer
1: On
2: Flashing (1 Hz)
5603 16 bits Read/write Retentive Behavior of digital output CON
in status ON
Only takes effect if register
5503 ≠ 0
Integer
1: On
2: Flashing (1 Hz)
Table 9-2 Register assignment
Type Address Value Access Memory Function Coding
