Modbus description
106377_en_04 PHOENIX CONTACT 59 / 68
Hold-
ing
7001 16 bits Read/write Retentive Configuring the operating time
of the charging connector
locking during opening and
closing
Relevant for EV-CC-AC1-M3-
CBC-... only
Integer, in ms
Default = 600 ms
7002 16 bits Read/write Retentive Maximum number of locking
cycles without cooling phase
Repetitions in the event of un-
successful locking attempts
Integer
Default = 5
7003 16 bits Read/write Retentive Break between two locking
sequences
Integer, in ms
Default = 1000 ms
7004 16 bits Read/write Retentive Maximum permissible operat-
ing time of the locking actuator
in continuous mode
Integer, in
Default = 50‰
7010 16 bits Read/write Retentive Evaluating the locking feed-
back
Setpoint resistance between
LD1 and LD2 in the “charging
connector not locked” status
Integer, in ohms
Default = 65535 (floating switch
as confirmation contact open)
7011 16 bits Read/write Retentive Evaluating the locking feed-
back
Setpoint resistance between
LD1 and LD2 in the “charging
connector locked” status
Integer, in ohms
Default = 0 (floating switch as
confirmation contact closed)
7500 16 bits Read/write Retentive Dimming the on-board LED
PWR
Integer, 1 x 16 bits
Percentage, pulse duty factor
0% 100%
7501 16 bits Read/write Retentive Dimming the on-board LED
CON
Integer, 1 x 16 bits
Percentage, pulse duty factor
0% 100%
7502 16 bits Read/write Retentive Dimming the on-board LED
ERR
Integer, 1 x 16 bits
Percentage, pulse duty factor
0% 100%
7503 16 bits Read/write Retentive Dimming the on-board LED
CHR
Integer, 1 x 16 bits
Percentage, pulse duty factor
0% 100%
Table 9-2 Register assignment
Type Address Value Access Memory Function Coding
