EV Charge Control Basic
60 / 68
PHOENIX CONTACT 106377_en_04
Coils 20000 1 bit Read/write Volatile Enabling the charging process
Switching on the PWM signal
if all other conditions required
are met.
Only takes effect if register
4000 is configured for this
function.
1 bit
0 = charging process not enabled
1 = charging process enabled
20001 1 bit Read/write Volatile Setting the system state F (ac-
cording to IEC 61851-1) if the
charging station is not avail-
able.
Only takes effect if register
4001 is configured via
Modbus/RTU.
1 bit
0 = charging station not available,
status F
1 = charging station available
20002 1 bit Read/write Volatile Controlling the locking actua-
tor
Only takes effect if register
4002 is configured for this
function.
1 bit
0 = charging connector is un-
locked
1 = charging connector is locked
20003 1 bit Read/write Volatile EV-RCM function test 1 = EV-RCM function test follow-
ing the next charging process
(status A1 or B1). After the func-
tion test, the register is set to 0.
21000 1 bit Read/write Volatile Restarting the charging con-
troller
1 bit
Restart if value 1 is written.
Hold-
ing
21100 16 bits Read/write Volatile Resetting to default settings Integer
Reset if value 17281 is written.
22000 16 bits Read/write Volatile Setting the maximum permis-
sible charging current
Integer
Maximum permissible charging
current
6 A 63 A
23000 16 bits Read/write Volatile Setting the digital output regis-
ter for output OUT
Only takes effect if the digital
output OUT is configured with
value 0 via register 5500 (see
Table 9-3).
Integer
0: Output = OFF
1: Output = ON
2: Output = flashing (1 Hz)
Table 9-2 Register assignment
Type Address Value Access Memory Function Coding
