Modbus description
106377_en_04 PHOENIX CONTACT 61 / 68
Hold-
ing
23001 16 bits Read/write Volatile Setting the digital output regis-
ter for output ERR
Only takes effect if the digital
output ERR is configured with
value 0 via register 5501 (see
Table 9-3).
Integer
0: Output = OFF
1: Output = ON
2: Output = flashing (1 Hz)
23002 16 bits Read/write Volatile Setting the digital output regis-
ter for output CHG
Only takes effect if the digital
output CHG is configured with
value 0 via register 5502 (see
Table 9-3).
Integer
0: Output = OFF
1: Output = ON
2: Output = flashing (1 Hz)
23003 16 bits Read/write Volatile Setting the digital output regis-
ter for output CON
Only takes effect if the digital
output CON is configured with
value 0 via register 5503 (see
Table 9-3).
Integer
0: Output = OFF
1: Output = ON
2: Output = flashing (1 Hz)
24000 16 bits Read Volatile System status according to
IEC 61851-1
2 x ASCII
A1, A2, B1, … , D2, E(0), F(0)
24001 16 bits Read Volatile If S1/DIP 7 = OFF: Proximity
evaluation according to IEC
61851-1 and assignment of
the current carrying capacity
of the charging connector ac-
cording to Table 5-1.
If S1/DIP 7 = ON: Connector
detection according to
GB/T 18487.1
Iff S1/DIP 7 = OFF
– 13 A, 20 A, 32 A, 63 A
– 0: PP open
– FFFF: 0 ohms between PP
and PE (error)
If S1/DIP 7 = ON
– 63 A: 0 ohms
– 0: PP open
24002 16 bits Read Volatile Charging current specification
via signal CP in % (pulse duty
cycle of the PWM signal ac-
cording to IEC 61851-1)
Integer
10% … 90%
24003 16 bits Read Volatile Charging current specification
via signal CP in A
Integer
6 A … 63 A
24004 16 bits Read Volatile Status of digital inputs 16 bits
Bit 0 – bit 4: EN, XR, ML, CCR,
IN
24005 16 bits Read Volatile Status of digital outputs 16 bits
Bit 0 – bit 3: OUT, ERR, CHG,
CON
Table 9-2 Register assignment
