EV Charge Control Basic
62 / 68
PHOENIX CONTACT 106377_en_04
Hold-
ing
24017 16 bits Read Volatile Minutes counter and seconds
counter in status C and D,
reset condition via status A
Integer, 2 x 8 bits
mm:ss
24018 16 bits Read Volatile Hours counter in status C and
D, reset condition via status A
Integer, 1 x 16 bits
hhhh
24019 16 bits Read Volatile Minutes counter and seconds
counter in status B, C and D,
reset condition via status A
Integer, 2 x 8 bits
mm:ss
24020 16 bits Read Volatile Hours counter in status B, C
and D, reset condition via sta-
tus A
Integer, 1 x 16 bits
hhhh
24025 16 bits Read Volatile Error status Bit = error assignment
Bit 2 = rejection of 13 A cable
Bit 3 = invalid PP value
Bit 4 = invalid CP value
Bit 5 = status F due to no
charging station availability
Bit 6 = locking
Bit 7 = unlocking
Bit 8 = LD unavailable during
locking
Bit 11 = status D, vehicle re-
jected
Bit 12 = charging contactor error
Bit 13 = no diode in the Control
Pilot circuit in the vehicle
Bit 15 = EV-RCM residual current
detection triggered
Bit 16 = EV-RCM selftest error
24027 16 bits Read – Presetting the maximum cur-
rent setting via S1/DIP 5 + 6
Integer, 1 x 16 bits
26000 16 bits Read Volatile Evaluating input EN as analog
input
Integer, 1 x 16 bits
Standardized to mV
26001 16 bits Read Volatile Evaluating input XR as analog
input
Integer, 1 x 16 bits
Standardized to mV
Table 9-2 Register assignment
Type Address Value Access Memory Function Coding
