Analog Inputs

MicIn:16xXLRBalanced(ch1-16)

LineIn:16xTRSBalancedjacks(Ch1-16)

Insert I/O 16xPhonejacks(Unbalanced)

2TR IN Analog 2xRCA(Unbalanced)

Stereo Output

2xXLRBalanced

2xRCA(Unbalanced)

Main Output 2xXLRBalanced

Control Room Output 2xXLRBalanced

Multi Outputs 8 x TRS Balanced

AUX/GroupOutput 8xTRSBalanced(SharedthroughMulti)

Phones 1xStereoPhonejack(TRSUnbalanced)

Digital I/O (AES/EBU)2xXLRBalanced

Sampling Frequency 44.1kHz,48kHz,88.2kHz,96kHz(40-BitFloatingPointMixing)

SignalDelay(CHINPUTtoSTEREOOUT) Fs=48kHz<1.2ms,Fs=96kHz<0.6ms

Faders 17 x 100mm motorized faders

Word Clock I/O 2 x BNC Connectors

Distortion(THD+N) THD+Nlessthan0.007%,+4dBu,20-20kHz,unitygain,20kHzBW

FrequencyResponse(CHINPUTtoSTEREOOUT) Fs=48,96kHz,0/-1.5dBu,20Hz–20kHz@+4dBuinto600Ω

Hum & Noise (20Hz–20kHz),Rs=150,-128dBu(EIN),-90dBu(residualoutputnoise)

Optional Expansion Card

A standalone 16-channel PCM WAV recorder and a Firewire/USB 2.0 multi-

trackrecordingaudiointerface;USB3.0ashdrivescompatible

VGA Monitor output D-Sub15pin:Progressivescanupto1024x768p@60Hz(XGA)

Ethernet 10/100 Base RJ45

USB2.0(MouseandWi-Fi) Type A x 2

Power Supply Unit 100V–240V,50/60Hz,90W

Dimensions(HxWxD) 169x495x534mm(6.65”x19.49”x21.02”)

Weight 17.0kg(37.5Ibs)

SPECIFICATIONS

Phonic IS16v1 User Manual
