phyFLEX
®
-i.MX 6
You can search for more available packages at:
http://layers.openembedded.org/layerindex/branch/master
/recipes/
Be sure that the layer on which the package depends is in our BSP. You can
check our integrated layers in the file conf/bblayers.conf .
When your needed layer is not in our BSP you must first checkout the layer
to the folder /opt/PHYTEC_BSPs/phyFLEX-i.MX6/source/ .
Please note that there is no a guarantee that the build process proceeds
successfully with all new packages added.
Now you can start building the configured BSP. There are two methods to
create the images. You can use either bitbake phytec-hwbringup-image, or
bitbake phytec-qt5demo-image
The first option leads to a faster compilation and smaller images, because all Qt relevant
features are left out.
In our example we want to keep the Qt relevant features, so we type following command:
bitbakephytec‐qt5demo‐image
Because of dead links it is possible that an attempt to download a source
package fails. PHYTEC cannot guarantee the accessibility of all the web
pages that are needed to build a BSP. In case of a failure please check our
ftp-server at ftp://ftp.phytec.de/pub/BSP_PACKAGES/EXTERNALS, and
download the source package from there into the source dire
ctory under
/opt/PHYTEC_BSPs/phyFLEX-i.MX6/build/downloads manually. After that,
please restart the build process by again calling
bitbake phytec‐
qt5demo‐image
orbitbakephytec‐hwbringup‐image.
If the package is also missing on our ftp-server, please send an email to
support@phytec.de. We will then take it from our build-server and upload
it onto our ftp-server for you.
Among other images you will find the kernel named zImage, the device tree named zImage-
imx6q-phytec-pbab01.dtb and the root file system named phytec-qt5demo-image-phyflex-
imx6-2.ubifs in the directory deploy/images/phyflex-imx6-2/.
The three files are only a symbolic link to the correct images with the timestamp of the
build date.
58
PHYTEC Messtechnik GmbH 2015 L-781e_7
