Remove the gas command fitting as indicated in
the photograph
Refitting the butterfly valve
To refit, perform the operations in the reverse or-
der from the removal operations being careful to
position the clip fixing the throttle body to the air
filter bellows at 45° as shown in the photograph.
MP3 250 i.e. Injection
INJEC - 15
