This section è is devoted to the operations that can be carried out on the vehicle's bodywork.
Seat
Lift the saddle and disconnect the rider presence
sensor.
Remove the three fixing screws.
Front handlebar cover
Remove the upper cap by operating on the Allen
screw indicated in the figure.
Remove the two brake pump caps.
Chassis MP3 250 i.e.
CHAS - 2
