Refitting the rocker-arms cover
- Refit the cylinder head cover, tightening the 5
clamping screws to the prescribed torque.
- Make sure the gasket is positioned properly.
Locking torques (N*m)
Tappet cover screws 6 - 7 Nm
Refitting the intake manifold
Fit the intake manifold and do up the three screws.
N.B.
USE COMMERCIALLY AVAILABLE INSERTS AND INSERT
HOLDERS FOR THE SPECIAL SCREWS FOR 125 CM³
MODELS.
Crankcase - crankshaft
Splitting the crankcase halves
First remove the following units:
transmission cover, driving pulley, driven pulley and belt, rear hub cover, gears, bearings and oil seals
as described in the transmission chapter.
- Remove the oil sump, the by-pass, the chain compartment cover and the oil pump as in the lubrica-
tion chapter.
Engine B 125-250
ENG - 168
