Unscrew the bayonet joint 1/8 of a turn, remove it,
take out the spring and vacuum valve plunger
Remove the 4 screws shown in the figure.
Remove the tank with the intake pump, its control
and gasket.
B 125-250 Engine
ENG - 197
