4 Disassembly & Re-assembly
4.1 Introduction
This section explains how to disassemble and reassemble the M3500A
multimeter. This section provides the procedure to assist in case cover
removal, main board removal, and front panel disassembly. Also, there are
mechanical drawings in this section to assist in the disassembly and
re-assembly of the M3500A.
Warning! Do not disassemble the M3500A multimeter unless you are
qualified to do so.
4.2 Case Cover Removal
If you need to remove the case cover when you are troubleshooting your
multimeter or you want to replace a component, this section will show you
how to do.
Warning! Do not remove the case cover before you disconnect the
line cord and all the test leads connecting to the multimeter, or electric
shock may occur.
NOTE: When you want to re-install the case cover, please reverse the steps
shown below. Make sure all the parts are properly seated and secured.
