4.5.5 GPIB Assembly
Before assembling the GPIB, operators have to disassemble the M3500A’s case cover. For more information about case cover
removal, please refer to the Section 4.2 Case Cover Removal. Then the GPIB assembly in the following just can proceed.
[Step 1]
Remove the screws by available tools.
[Step 2]
Remove the screws on the other side by available tools.
