B. General Specifications
item Limitation & description
Power Supply
100V/120V/220V/240V ± 10%
Power Line Frequency
50~60 Hz ± 10%
Power Consumption 25 VA peak (16 W average)
Operating Environment
0 ℃ to 40 ℃
Operating Humidity
Maximum relative humidity 80% for temperature
up to 31 ℃ decreasing linearly to 50% relative
humidity at 40℃
Storage Temperature
- 40 ℃ to 70 ℃
Operating Altitude Up to 2000m
Bench Dimensions for
Rack (WxHxD)
213.6 x 88.6 x 370.0 mm
Weight
3706 g
Safety
IEC61010-1:2001/EN61010-1:2001 (2
nd
Edition)
Over-Voltage Category CAT II, CAT I 1000V
UL61010-1:2004
Installation CAT II, Measurement CAT III at max. 1000V
Pollution Degree 2
EMC
EN61326-1:2006
EN61326-2-1:2006
EMI:
CISPR 11:1997+A1:1999+A2:2002 Class B
IEC61000-3-2:2000
IEC61000-3-3:1994+A1:2001
EMS:
IEC61000-4-2:1995+A1:1998+A2:2000
IEC61000-4-3:2002
IEC61000-4-4:2004
IEC61000-4-5:1995+A1:2000
IEC61000-4-6:1996+A1:2000
IEC61000-4-8:1993+A1:2000
IEC61000-4-11:1994+A1:2000
※Note: Regarding the Safety, the LO jack is marked with 500Vpk against
ground and SENSE HI to LO is only marked with 200Vpk, in opposition to the
label of 600V CAT II and/or 1000V CAT I against ground and IEC 61010-1.
