Picotest M3500A - AC Characteristics

91
AC Characteristics
Function Range
Frequency
(Hz)
24 hours accuracy
±
(% of reading+% of
range)(23
o
C
±
1
o
C)
1 year accuracy
±
(% of reading+% of
range)(23
o
C
±
5
o
C)
ACV
(AC RMS
Voltage)
100.0000
mV
3 – 5 1.00+0.03 1.00+0.04
5 – 10 0.35+0.03 0.35+0.04
10 – 20K 0.04+0.03 0.06+0.04
20K – 50K 0.10+0.05 0.12+0.05
50K – 100K 0.55+0.08 0.60+0.08
100K–300K 4.00+0.50 4.00+0.50
1.000000
V
to
750.000 V
3 – 5 1.00+0.02 1.00+0.03
5 – 10 0.35+0.02 0.35+0.03
10 – 20K 0.04+0.02 0.06+0.03
20K – 50K 0.10+0.04 0.12+0.05
50K – 100K 0.55+0.08 0.60+0.08
100K–300K 4.00+0.50 4.00+0.50
ACI
(AC RMS
Current)
1.000000 A
3 – 5 1.00+0.04 1.00+0.04
5 – 10 0.30+0.04 0.30+0.04
10 – 5K 0.10+0.04 0.10+0.04
3.00000 A
3 – 5 1.10+0.06 1.10+0.06
5 – 10 0.35+0.06 0.35+0.06
10 – 5K 0.15+0.06 0.15+0.06
(※Note 1: Specifications are for 2-hour warm-up at 6.5 Digits, slow ac filter
with Bandwidth 3Hz, sine wave input.)
(※Note 2: 750Vac range limited to 100 KHz)
