NOTE: When you want to re-install the front panel, please reverse the steps
shown above. Make sure all the parts are properly seated and secured.
4.5 Assembly Drawings
The mechanical drawings provided in this section will help you to
disassemble and re-assemble the M3500A multimeter quickly. Section
4.5.1 shows the front panel assembly, section 4.5.2 shows the chassis and
transformer assembly, section 4.5.3 is the main board assembly, and
section 4.5.4 provides the chassis assembly drawings.
