Picotest M3500A - Page 79

79
060-002-00001Z 500K tolerance:0.1%,5PPM R606
060-002-00009K
RN6008 TCK10-.1-1%-10PPM-LOWEMF
Thermal EMF <= +-0.5uV/k
TCR <= +-10ppm/k
R323
060-006-000001 MAX10R000B R317
060-006-000001 MAX10R000B R324
060-008-000001 USVD2-B10M-025-02 R204
061-003-000004 MPF4392 Q601
061-004-000001 2SK1412LS Q301
061-004-000001 2SK1412LS Q302
061-006-000002 KBL04 Bridge rectifier D102
062-001-000001 317-037 U type heat sinker with pin U2201
062-001-000001 317-037 U type heat sinker with pin U2203
062-001-000001 317-037 U type heat sinker with pin U2205
062-001-000001 317-037 U type heat sinker with pin U2207
063-004-000003 VRE310JD U802
063-004-000007 MC7818CT U2201
063-004-000009 MC7918CT U2203
063-004-00000B LM1117T-5V U2207
063-004-00000C LM1117T-3.3V U2205
063-011-000002 10MHz Y1601
063-011-000003 6MHz Y2101
Table 5-1
Parts list of M3500A panel board
Picotest Part NO.
Description Circuit Design
056-001-000003 100nF-0603 X7R,50V,10% C1
056-001-000003 100nF-0603 X7R,50V,10% C11
056-001-000003 100nF-0603 X7R,50V,10% C15
056-001-000003 100nF-0603 X7R,50V,10% C22
056-001-000003 100nF-0603 X7R,50V,10% C3
056-001-000003 100nF-0603 X7R,50V,10% C4
056-001-000003 100nF-0603 X7R,50V,10% C5
056-001-000003 100nF-0603 X7R,50V,10% C7
056-001-000003 100nF-0603 X7R,50V,10% C8
056-001-00000B 10nF-0603 X7R,50V,10% C14
056-001-00000B 10nF-0603 X7R,50V,10% C18
056-001-00000B 10nF-0603 X7R,50V,10% C19
056-001-00000H 100pF-0603 NPO,50V,5% C17
056-001-00000L 1nF-0603 X7R,50V,tolerance:10% C16
