PNOZ s5
Operating Manual PNOZ s5
21397-EN-10
19
Operation
NOTICE
The safety function should be checked after initial commissioning and each
time the plant/machine is changed. The safety functions may only be
checked by qualified personnel.
The unit is ready for operation when the Power LED is permanently lit.
LEDs indicate the status and errors during operation:
LED on
LED flashes
LED off
INFORMATION
Status indicators and error indicators may occur independently. In the case
of an error display, the "Fault" LED will light or flash (exception: "Supply
voltage too low"). An LED that is also flashing indicates the potential cause
of the error. An LED that is lit and is static indicates a normal operating
status. Several status indicators and error indicators may occur simultan-
eously.
Status indicators
POWER
Supply voltage is present.
IN1
Input circuit at S12 is closed.
IN2
Input circuit at S22 is closed.
OUT
Safety contacts are closed and semiconductor output Y32 carries a high signal.
RESET
24 VDC is present at S34.
OUT
Set delay time is running.
