Operating Manual PNOZ s5
21397-EN-10
37
Remove plug-in terminals
Procedure: Insert the screwdriver into the housing recess behind the terminal and lever the
terminal out.
Do not remove the terminals by pulling the cables!
Order reference
Product type Features Connection type Order No.
PNOZ s5 24 VDC Screw terminals 750 105
PNOZ s5 C 24 VDC Spring-loaded terminals 751 105
PNOZ s5 C
(coated version)
24 VDC Spring-loaded terminals 751 185
PNOZ s5 48 - 240 VAC/DC Screw terminals 750 135
PNOZ s5 C 48 - 240 VAC/DC Spring-loaded terminals 751 135
EC declaration of conformity
This product/these products meet the requirements of the directive 2006/42/EC for ma-
chinery of the European Parliament and of the Council. The complete EC Declaration of
Conformity is available on the Internet at www.pilz.com/downloads.
Representative: Norbert Fröhlich, Pilz GmbH & Co. KG, Felix-Wankel-Str. 2, 73760 Ost-
fildern, Germany
