Content
Operating Manual PNOZ s5
21397-EN-10
3
Introduction 5
Validity of documentation 5
Using the documentation 5
Definition of symbols 5
Safety 6
Intended use 6
Safety regulations 6
Safety assessment 6
Use of qualified personnel 6
Warranty and liability 7
Disposal 7
For your safety 7
Unit features 8
Safety features 8
Block diagram/terminal configuration 9
Type: 24 VDC 9
Type: 48 - 240 VAC/DC 9
Function description 10
Timing diagrams 11
Automatic and manual start 11
Monitored start 12
Reset with start-up test 13
Installation 14
Wiring 14
Preparing for operation 15
Operating modes and delay time 15
Set operating modes 16
Set delay time 16
Connection 16
Operation 19
Status indicators 19
Error indicators 20
Faults - malfunctions 21
Dimensions in mm 21
Technical details 22
Safety characteristic data 33
