PNOZ s5
Operating Manual PNOZ s5
21397-EN-10
22
Technical details
Order no. 750105 – 751185
See below for more order numbers
General 750105 751105 751185
Approvals
CCC, CE, EAC (Euras-
ian), KOSHA, TÜV, cU-
Lus Listed
CCC, CE, EAC (Euras-
ian), KOSHA, TÜV, cU-
Lus Listed
CCC, CE, EAC (Euras-
ian), KOSHA, TÜV, cU-
Lus Listed
Electrical data 750105 751105 751185
Supply voltage
Voltage 24 V 24 V 24 V
Kind DC DC DC
Voltage tolerance -15 %/+10 % -15 %/+10 % -15 %/+10 %
Output of external
power supply (DC) 4 W 4 W 4 W
Residual ripple DC 20 % 20 % 20 %
Continuous duty 100 % 100 % 100 %
Inputs 750105 751105 751185
Number 2 2 2
Voltage at
Input circuit DC 24 V 24 V 24 V
Start circuit DC 24 V 24 V 24 V
Feedback loop DC 24 V 24 V 24 V
Current at
Input circuit DC 40 mA 40 mA 40 mA
Start circuit DC 40 mA 40 mA 40 mA
Feedback loop DC 40 mA 40 mA 40 mA
Max. inrush current im-
pulse
Current pulse, input cir-
cuit 0,2 A 0,2 A 0,2 A
Pulse duration, input
circuit 100 ms 100 ms 100 ms
Current pulse, feed-
back loop 0,2 A 0,2 A 0,2 A
Pulse duration, feed-
back loop 60 ms 60 ms 60 ms
Current pulse, start cir-
cuit 0,2 A 0,2 A 0,2 A
Pulse duration, start
circuit 60 ms 60 ms 60 ms
Min. input resistance at
power-on 110 Ohm 110 Ohm 110 Ohm
