Operating Manual PNOZ s5
21397-EN-10
23
Inputs 750105 751105 751185
Max. overall cable resist-
ance Rlmax
Single-channel at UB
DC 30 Ohm 30 Ohm 30 Ohm
Dual-channel without
detection of shorts
across contacts at UB
DC 30 Ohm 30 Ohm 30 Ohm
Dual-channel with de-
tection of shorts across
contacts at UB DC 30 Ohm 30 Ohm 30 Ohm
Semiconductor outputs 750105 751105 751185
Number 1 1 1
Voltage 24 V 24 V 24 V
Current 20 mA 20 mA 20 mA
Relay outputs 750105 751105 751185
Number of output con-
tacts
Safety contacts (N/O),
instantaneous 2 2 2
Safety contacts (N/O),
delayed 2 2 2
Max. short circuit current
IK 1 kA 1 kA 1 kA
Utilisation category
In accordance with the
standard EN 60947-4-1 EN 60947-4-1 EN 60947-4-1
Utilisation category of
safety contacts
AC1 at 240 V 240 V 240 V
Min. current 0,01 A 0,01 A 0,01 A
Max. current 6 A 6 A 6 A
Max. power 1500 VA 1500 VA 1500 VA
DC1 at 24 V 24 V 24 V
Min. current 0,01 A 0,01 A 0,01 A
Max. current 6 A 6 A 6 A
Max. power 150 W 150 W 150 W
Utilisation category of
safety contacts delayed
AC1 at 240 V 240 V 240 V
Min. current 0,01 A 0,01 A 0,01 A
Max. current 6 A 6 A 6 A
Max. power 1500 VA 1500 VA 1500 VA
DC1 at 24 V 24 V 24 V
Min. current 0,01 A 0,01 A 0,01 A
Max. current 6 A 6 A 6 A
Max. power 150 W 150 W 150 W
