PNOZ s5
Operating Manual PNOZ s5
21397-EN-10
9
Block diagram/terminal configuration
Type: 24 VDC
} U
B
: 24 VDC; Order No. 750105, 751105, 751185
Interface
expansion
module
Fig.: Centre: Front view with cover, right: Front view without cover
*Insulation between the non-marked area and the relay contacts: Basic insulation (over-
voltage category III), Protective separation (overvoltage category II)
Type: 48 - 240 VAC/DC
} U
B
: 48 – 240 VAC/DC; Order No. 750135, 751135
Interface
expansion
module
Fig.: Centre: Front view with cover, right: Front view without cover
*Insulation between the non-marked area and the relay contacts: Basic insulation (over-
voltage category III), Protective separation (overvoltage category II)
