PNOZ s5
Operating Manual PNOZ s5
21397-EN-10
25
Conventional thermal
current while loading
several contacts
750105 751105 751185
Ith per contact at UB DC
AC1:240V,DC1:24V
Conv. therm. current
with 1 contact 6 A 6 A 6 A
Conv. therm. current
with 2 contacts 6 A 6 A 6 A
Conv. therm. current
with 3 contacts 6 A 6 A 6 A
Conv. therm. current
with 4 contacts
6 A 6 A 6 A
Times 750105 751105 751185
Switch-on delay
With automatic start
typ. 180 ms 180 ms 180 ms
With automatic start
max. 330 ms 330 ms 330 ms
With automatic start
after power on typ. 1.430 ms 1.430 ms 1.430 ms
With automatic start
after power on max. 1.900 ms 1.900 ms 1.900 ms
With automatic start
after power on typ. 1.470 ms 1.470 ms 1.470 ms
With automatic start
after power on max. 2.000 ms 2.000 ms 2.000 ms
With manual start typ. 45 ms 45 ms 45 ms
With manual start max. 85 ms 85 ms 85 ms
With monitored start
with rising edge typ. 45 ms 45 ms 45 ms
With monitored start
with rising edge max. 70 ms 70 ms 70 ms
With monitored start
with falling edge typ. 60 ms 60 ms 60 ms
With monitored start
with falling edge max. 80 ms 80 ms 80 ms
Delay-on de-energisation
With E-STOP typ. 15 ms 15 ms 15 ms
With E-STOP max. 20 ms 20 ms 20 ms
With power failure typ. 75 ms 75 ms 75 ms
With power failure max. 110 ms 110 ms 110 ms
Recovery time at max.
switching frequency 1/s
After E-STOP 150 ms +tv 150 ms +tv 150 ms +tv
After power failure 200 ms 200 ms 200 ms
