First commissioning
Operating Manual PSEN sc B 5 Series
1004508-EN-02
48
Suitable Pilz evaluation devices are, for example:
} PNOZmulti for monitoring safety laser scanners
Configure the safety laser scanner in PNOZmulti Configurator as a function element
"Light curtain" with switch type3.
} Automation system PSS 4000
The correct connection to the respective evaluation device is described in the operating
manual for the evaluation device. Connect the evaluation device according to the specifica-
tions in the selected evaluation device’s operating manual.
9.3 Configuration of zones
For simultaneous monitoring of several zones and the switching of monitoring of zone sets,
the configurable inputs of the safety laser scanner must be configured appropriately.
} Configuration of a static zone set
No configurable inputs are required.
} Configuration of two zone sets
Configure two configurable inputs.
} Configuration of three zone sets
Configure three configurable inputs.
9.3.1 Example configuration A
Settings in PSENscan Configurator for
wiring example A [ 39]: 1 zone set, 1 warning,
automatic restart
Procedure:
1. From the start page, select Create new configuration.
The window Device selection is displayed with one tab each Online and Overview of
all types.
2. Select a device from Overview of all types. Double-click the device.
The device is displayed in the work window and it can be configured.
3. Under Application, select EXPERT and 8-pin connection.
Configuration
You can enter a title for the configuration under Name.
You can enter the name of the person who created the configuration under Author.
You can describe the configuration in detail under Description.
The Configurator Version is entered by the system and cannot be changed.
The Check sum is entered by the system and cannot be changed.
The Creation date is entered by the system and cannot be changed.
Device
You can enter a title for the connected device under Name.
Click on the arrow
. The next window is opened: Output configuration. The number
of OSSD pairs is already selected.
