First commissioning
Operating Manual PSEN sc B 5 Series
1004508-EN-02
53
8. Select the detection capability [mm] for this safety laser scanner. Define the value for
Safety zone or for Warning zone.
9. Select Dust filter level (level1=low, level 3=high).
A higher level of dust filtering requires a longer safety distance.
WARNING!
Loss of safety function due to a safety distance that is too low
Depending on the application, serious injury or death may result.
} Depending on the degree of dust filtering, it is necessary to consider an
allowance for calculating the safety distance when installing the safety
laser scanner near intense light sources or reflective surfaces into ac-
count (see
Distance to intense light sources and to reflective
surfaces [ 24]).
– When calculating the safety distance, ensure that the allowance is
considered depending on the dust filtering.
– Ensure that the new safety distance fulfils the specifications of the
safety assessment.
9.3.4 Example configuration D
Settings in PSENscan Configurator for
wiring example [ 39] D: 3 zone sets, no warning,
automatic restart
Procedure:
1. From the start page, select Create new configuration.
The window Device selection is displayed with one tab each Online and Overview of
all types.
2. Select a device from Overview of all types. Double-click the device.
The device is displayed in the work window and it can be configured.
3. Under Application, select EXPERT and 8-pin connection.
Configuration
You can enter a title for the configuration under Name.
You can enter the name of the person who created the configuration under Author.
You can describe the configuration in detail under Description.
The Configurator Version is entered by the system and cannot be changed.
The Check sum is entered by the system and cannot be changed.
The Creation date is entered by the system and cannot be changed.
Device
You can enter a title for the connected device under Name.
Click on the arrow
. The next window is opened: Output configuration. The number
of OSSD pairs is already selected.
