16 Captain-i - Installation Guide
Connect the 3 wires to the connection terminals of the transformer housing. Be sure to
connect them in the correct order. Check for continuity between the control unit
grounding point and the electrical plug grounding point with an ohmmeter. The
resistance must be less than 1Ω.
3.1.12 Battery
The CAPTAIN-i is designed to operate with a rechargeable 12-V battery.
The charging voltage is 13.8 V.
The system performs a load battery test each time:
The system is armed
Every 1 hour
Upon connecting to power
If the test fails, the system will respond as programmed in the failures responses
(sounding sirens, dialing the Monitoring Station, etc.).
3.2 Initial operations & Programming devices
Check that all the connections are as described previously and then connect the system
to mains. After a few seconds, the following screens are displayed (in
RXN-400/410 LCD Keypads):
Keypad Ver. 1.15
Keypad ID:0
...
Starting
Please wait...
1 JAN 07 00:00
Clock not set
Several seconds after power connection, the hour 00:00 and the status of the zones
are displayed. In addition, the red Fault LED will be flashing (Other faults, if exist, will
also be displayed).
Connect the battery to the black and red fast-connect terminals: the red wire to the
(+) and the black wire to the (-). Be sure to connect the wires correctly!
Note: If the battery is connected before mains, “AC Fault” is triggered, until the mains
is connected
At this point, enter the Primary Code (factory default Primary (Master) Code is 5555)
and set the correct hour and date as follows:
[ Primary Code [ [
HOUR
0 :0
Enter current time (HH:MM);
[ [
YEAR MONTH DAY
0 1 1
Enter current date (YY MM DD); [ .
