A parameter required by the NPAF protocol only.
Consult the CMS.
Handshake Wait: how long the control panel will wait
for a Handshake message, before disconnecting the call
and redialing.
Kissoff Wait: how long the control panel will wait for a
Kissoff message, before resending it. Change the
default only if necessary, for example if there are
communication delays.
ACK Frequency: select between Lo-Hi, 1400, 2300, and
SIA.
A daily test report to the CMS; press # to reset and
disable reporting.
An interval (in hours) for a test report to the CMS. If
longer than 24 hours, the interval will start over every
time it overlaps the Periodic test.
The number of dials and redials that if fail (no ACK is
received), a communication fault is reported.
Select if the telephone is the primary path for reporting
the CMS.
2) Cellular-Voice: see the Telephone (PSTN) menu above.
3) Network (Ethernet): in addition to the above Telephone (PSTN) parameters, the network
has the following parameters:
IP/URL 1-2: the CMS’s IP/URL address. Address #2 only serves as a backup.
Port 1-2: enter the port no.
Supervision (test) report interval. The report is
designated to the IP receiver at the CMS.
0 (disabled) -
59:59 mm:ss
Set the number of retries if no ACK is received.
Data will be not encrypted. Verify that CMS IP
receiver is adjusted for non-encrypted reports.
Caution
Non-encrypted reporting causes the system and
the CMS to be more vulnerable to cyber attacks!
The account ID field in the report frame will
always be 16 digits, with leading '0'. Use this
feature only by special request from the CMS.
4) Cellular Data: see Network (Ethernet) above.
Event Reporting
System Configuration
CMS & Communications
Monitoring Stations
CMS 1-3
Event Reporting
Select the events to report to the CMS. The optional events are:
▪ Alarms: Burglary, Panic, Fire, Duress, Medical, Tamper, Custom Zone 1-5.
