8) Soak Test Mode: select to put the zone in test mode for up to one week; see section 8, on
page 24 for details.
4.2 Zone Types Settings
System Configuration
Zones
Zone Types Settings
Some settings are built-in and cannot be changed. If a different setting is
required, use the Custom Zone types.
Burglary, Panic, Silent
Panic, Fire, Duress,
Medical, Anti-Mask,
Shock Sensor, Key
Switch Modes,
Custom Zone Types
1) Sensitivity: the zone sensitivity in milliseconds.
Range: 1-3000, default: 400.
Closing the relay for one second re-sets the detector.
2) Attributes: see next.
3) Audible Notification:
▪ Alarm tone: when calling the contacts, hi-lo alarm will be
▪ Message 1 – Recorded message #1 will be activated.
▪ Message 2 – Recorded message #2 will be activated.
▪ Notes:
o Message 1 &2 use Voice Module VOX502 (purchased
separately).
o Configure Output Type (see paragraph 5) of the VOX502
outputs accordingly – Message 1 or 2.
Key Switch in Away/Home 1-4: select the key type and set its
sensitivity (see above).
1) Custom Zone Type 1-5: see the other zone types above, and in
addition:
• Report & Trigger: select a standard zone type (Burglary,
Panic, etc.) to be used for reporting the CMS and triggering
outputs or select a
Custom Type
. A
Custom Type
can be used
to trigger outputs to activate/deactivate special devices such
as pumps and heaters).
• Name: user text, up to 16 characters.
4.2.1 Attributes
System Configuration
Zones
Zone Types Settings
Zone Type
Attributes
The zone type attributes are listed in the table below:
The sirens will activate in alarm (via the
External
and
Internal Siren
programmed output types; see section 5.1, on page 15 for a warning).
The external siren will activate in alarm (via the
External
Siren
programmed output type) while at disarm.
Reports to the CMS will be transmitted while at disarm
