5: Outputs
15
5 Outputs
8
The Outputs menu includes the following sub-menus:
1) Onboard: see below.
2) Zone Expanders: see section 5.2.
3) Outputs Expander: see section 5.3.
4) Wireless Sirens: see section 5.4.
5.1 Onboard
System Configuration  Outputs  Onboard
The Onboard menu includes the following sub-menus (outputs):
1) External Siren
2) Internal Siren
3) Relay
4) On/Off
5) Alarm
5.1.1 Ext/Int siren outputs
The external and internal siren outputs have the following features:
▪ Supplying high current
▪ Can only trigger DC sirens
▪ Can be triggered separately
Warning: the sirens outputs will be triggered only if you do not change
the sirens’ default programmed output types.
Every output has the following parameters:
Parameter
Description
Output Type
The output type (event) that triggers the selected physical output. The
triggering timer is set in the Timers and Counters menu; see Appendix C for
the complete list of the output types.
The next types are followers only.
Programmable
output type
Triggered when...
Zone open
a zone is opened
Arm Away
the system (or all partitions) is armed Away
Arm Home
the system (or all partitions) is armed in Home 1-4
Technician on-site
Technician code is entered
Walk test
Walk test started
The default programmable output types do not need
to be changed in most installations.
8
FORCE only, except Wireless Sirens .
