Pima FORCE Programming Guide

4: Zones
11
4 Zones
The Zones menu includes the following sub-menus:
1) Zone Settings; see below.
2) Zone Type Settings; see section 6), on page 11.
3) Copy Zones; see section 4.3, on page 14.
4) Partitions Names; see section 4.3.2, on page 14.
4.1 Zone Settings
System Configuration  Zones  Zone Settings
Press * or # to select a zone.
1) Type: select the zone type from the list; see the list below.
2) Name: user text, up to 28 characters.
3) Delay/24H: select from the following options.
Parameter
Description
Instant
Instant alarm zone
Entry Delay 1-2
Entry delayed zones
Delay Follower
Delay following zone
24-Hour
24-hour alarm zone
4) Attributes: select from the following list.
Parameter
Description
Disabled
The zone is permanently inactive
Normally Open
• Selected: Normally Open
• Cleared: Normally Close
Allocated to Home 1-4
Allocate the zone to a Home mode
EOL Supervision
5
Cut and/or short
6
zone supervision
Chime Zone
The keypad buzzer will sound when the zone is opened
Roller Blinds
The zone’s sensitivity is adjusted to roller blinds
5) False Alarms: select from the list that follows ( Inactive is also an option).
Parameter
Description
Double Knock
The zone will trigger the alarm, only if two pulses are detected during the
Double Knock time (see section 8, on page 24).
Cross Zoning
The zone will trigger the alarm, only if another cross zone is opened too,
during the Cross Zoning time (see 8, on page 24).
6) Partition Allocation: allocate the zone to partition/s; the selected number/s will stay on.
7) Wireless Zones
This menu refers to wireless zones parameters only. Each parameter is relevant to specific
detector type or types. See the following table:
5
FORCE only
6
Depending on the defined number of resistors. See section 9, on page 42.
